major type and technical parameters

    Type Diameter (mm) Tension range (g)

    MTCSS ф0.03 --- ф0.07 4 --- 40

    MTCS ф0.04 --- ф0.14 7 --- 100

    MTCM ф0.08 --- ф0.25 15 --- 500

    MTCL ф0.12 --- ф0.35 50— 750

    MTCL ф0.14 --- ф0.40

         adjusting method of the tension in use:

    tension situation   Working point of the tension rod   adjusting method

    tension: Large/small fine-tuning knob of back tension: Left/ Right

    ----- working point of the tension rod big/ small  tuning knob of the upper part tension Left/ Right

   tension: Small working point of the tension rod: large fine-tuning knob of back tension: Right

   tension: Small working point of the tension rod: small tuning knob of upper part tension: Left

   tension: Large working point of the tension rod: large tuning knob of upper part tension: Right

  tension: Large working point of the tension rod: small fine-tuning knob of back tension: Left
